Dew Point Meter

Product Details:

Digital Online Dew Point Monitor Process Dew Point Analyzer Designed to Handle Rigorous Demands of Moisture and Dew Point Measurement in Compressed air & Natural Gas. Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution for Demanding and Critical Moisture Monitoring Applications.

Application:

• Natural Gas
• Hydrocarbon Processing
• Catalyst Protection
• Heat Treating
• Industrial Gases
• Dryer & Compressed Air



Product Details:

Battery Operated Dew Point Meter indicate the amount moisture in the air. The higher the dew points, the higher the moisture content of the air at a given temperature. Dew point temperature is defined as the temperature to which the air would have to cool (at constant pressure and constant water vapor content) in order to reach saturation. A state of saturation exists when the air is holding the maximum amount of water vapor possible at the existing temperature and pressure.When the dew point temperature and air temperature are equal, the air is said to be saturated. Dew point temperature is Never Greater than the air temperature. Therefore, if the air cools, moisture must be removed from the air and this is accomplished through condensation. This process results in the formation of tiny water droplets that can lead to the development of fog, frost, clouds, or even precipitation. Relative Humidity can be inferred from dew point values. When air temperature and dew point temperatures are very close, the air has a high relative humidity. The opposite is true when there is a large difference between air and dew point temperatures, which indicates air with lower relaitve humidity. Locations with high relative humidities indicate that the air is nearly saturated with moisture; clouds and precipitation are therefore quite possible. Weather conditions at locations with high dew point temperatures (65 or greater) are likely to be uncomfortably humid.Applied portable handheld battery operated Dew Point meter model ATS-301D are designed to measures dew point, Moisture and temperature faster and accurately over a wide measurements range . Model ATS-301D is highly optimized to measure the dew point, moisture and Temperature for dryers and compressed air/gases.

Features:

• Robust & Reliably Construction for Industrial Applications
• Micro controller based embedded intelligent instrument
• Multi Parameter Single 128 X 64 LCD Display
• Embedded software for moisture calculation in PPM
• Samples Pressure Upto 12 Kg/C2M
• Inbuilt Thin film Capacitive sensor
• Optional Auto & Manual Data Logging systems with RS 232/USB Computer Interface

Application:

• Dryer & Compressed Air
• Laboratory Analysis
• Light bulb manufacturing
• Industrial gas manufacturing
• Heat treatment/Food Packaging
• Petrochemical / Petroleum industry

Specifications:

• Range : -60 to 30 Deg C
• Principle: Thin Film Capacitive
• Range: Degree C, PPM & % RH
• Resolution: 0.1 Unit or 1 Unit (Application based)
• Sampling Method: Direct Plug In
• Display: 128 X 64 Graphics LCD
• Power Source: Built in Lithium Rechargeable battery
• Accuracy: /2%
• Response Time: <5 Second
• Data Storage: 5000 or 10000
• Computer Interface: RS 232, USB
• Sensor Life: 2-3 Years
• Operating Time: 6 – 8 hours

Environmental:

• Temperature:-15degree Celsius Humidity :< 85%RH Atmosphere Pressure: 86- 106Kpa
• Housing: High Impact Plastic
• Dimension in mm: 130 (W) X 250 (H) X 90(D)
• Weight: 0.5 KG
• Warranty: One Year



Product Details:

Being the market leader in this domain, we are actively committed towards offering a wide range of Digital Dew Point Meter. It is highly optimized to measure the dew point, moisture and Temperature for dryers and compressed air/gases. The dew point (dew point temperature) is the temperature at which dew forms and is a measure of atmospheric moisture.The dew point is the saturation temperature for water in air. The dew point is associated with relative humidity. A high relative humidity implies that the dew point is closer to the current air temperature. Relative humidity of 100% indicates the dew point is equal to the current temperature and that the air is maximally saturated with water. When the moisture content remains constant and temperature increases, relative humidity decreases. This meter is manufactured by our professionals using best grade factor inputs in compliance with industry quality standards. To ensure quality and flawlessness, the entire array is well tested against various quality parameters. Further, clients can avail this meter from us at affordable prices within stipulated time frame.

Features:

• High efficiency,
• Require less maintenance,
• Industry approved design

Specifications:

• Principle: Thin Film Capacitive ,
• Range: Degree C, PPM & % RH
• Resolution: 0.1 Unit or 1 Unit (Application based)
• Sampling Method: Direct Plug In
• Display: 128 X 64 Graphics LCD
• Power Source: Built in Lithium Rechargeable battery
• Accuracy: /2%
• Response Time
• Data Storage: 5000 or 10000
• Computer Interface: RS 232, USB
• Sensor Life: 2-3 Years
• Operating Time: 6 – 8 hours
• Temperature:-15degree Celsius
• Humidity :< 85%RH
• Atmosphere Pressure: 86- 106Kpa
• Housing: High Impact Plastic
• Dimension in mm: 130 (W) X 250 (H) X 90(D)
• Weight: 0.5 KG
• Warranty: One Year.



Product Details:

Online Dew Point Meter Designed to Handle Rigorous Demands of Moisture and Dew Point Measurement in Compressed air & Natural Gas Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution for Demanding and Critical Moisture Monitoring Applications.



Application:

• Natural Gas
• Hydrocarbon Processing
• Catalyst Protection
• Heat Treating
• Industrial Gases
• Dryer & Compressed Air

Product Details:

Counted as one of the prominent organizations, we are engaged in providing a wide range of superior quality Dew Point Analyser. This analyser is manufactured using exceptional quality raw-material and advanced technology by our skilled professionals. It is designed to measures dew point, Moisture and temperature faster and accurately over a wide measurements range. In order to ensure quality, this analyser is stringently tested on different parameters by our experts. Apart from this, remarkable quality and sturdy structure increase the demand of our offered range in the market. Dew points indicate the amount moisture in the air. The higher the dew points, the higher the moisture content of the air at a given temperature. Dew point temperature is defined as the temperature to which the air would have to cool (at constant pressure and constant water vapor content) in order to reach saturation. A state of saturation exists when the air is holding the maximum amount of water vapor possible at the existing temperature and pressure. When the dew point temperature and air temperature are equal, the air is said to be saturated. Dew point temperature is Never Greater than the air temperature. Therefore, if the air cools, moisture must be removed from the air and this is accomplished through condensation. This process results in the formation of tiny water droplets that can lead to the development of fog, frost, clouds, or even precipitation. Relative Humidity can be inferred from dew point values. When air temperature and dew point temperatures are very close, the air has a high relative humidity. The opposite is true when there is a large difference between air and dew point temperatures, which indicates air with lower relaitve humidity. Locations with high relative humidities indicate that the air is nearly saturated with moisture; clouds and precipitation are therefore quite possible. Weather conditions at locations with high dew point temperatures (65 or greater) are likely to be uncomfortably humid.

Features:

• Rugged construction
• Unmatched performance
• Trouble-free operation

Other Details:

• Robust Reliably Construction for Industrial Applications
• Micro controller based embedded intelligent instrument
• Multi Parameter Single 128 X 64 LCD Display
• Embedded software for moisture calculation in PPM
• Samples Pressure Upto 12 Kg/C2M
• Inbuilt Thin film Capacitive sensor
• Optional Auto Manual Data Logging systems
• RS 232/USB Computer Interface



Specification:

• Principle Thin Film Capacitive
• Range Degree C, PPM % RH
• Resolution0.1 Unit or 1 Unit (Application based)
• Sampling Method Direct Plug In
• Display128 X 64 Graphics LCD
• Power Source Built in Lithium Rechargeable battery
• Accuracy/2%
• Response Time
• Data Storage5000 or 10000
• Computer Interface RS 232, USB Sensor
• Operating Time 6 - 8 hours
• Dimension in mm130 (W) X 250 (H) X 90(D)
• Weight0.5 KG

• Warranty One Year





Application:

• Dryer Compressed Air
• Laboratory Analysis
• Light bulb manufacturing
• Industrial gas manufacturing
• Heat treatment/Food Packaging
• Petrochemical / Petroleum industry



Product Details:

Model ATS-303D Process Dew Point Meter Designed to Handle Rigorous Demands of Moisture and Dew Point Measurement in Compressed air & Natural Gas Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution for Demanding and Critical Moisture Monitoring Applications.



Application:

• Natural Gas
• Hydrocarbon Processing
• Catalyst Protection
• Heat Treating
• Industrial Gases
• Dryer & Compressed Air

Product Details:

We are the manufacturer of Handheld Digital Dew Point Meter with range of -80 to + 30 Deg C in India Dew Point Indicator Applied portable handheld battery operated Dew Point Meter model ATS-301D are designed to measures dew point, Moisture and temperature faster and accurately over a wide measurements range . Model ATS-301D is highly optimized to measure the dew point, moisture and Temperature for dryers and compressed air/gases.

Specifications:

• Principle: Thin Film Capacitive Sensor
• Range: Degree C, PPM & % RH
• Resolution: 0.1 Unit or 1 Unit (Application based)
• Sampling Method: Direct Plug In, Optional suction pump
• Display: 128 X 64 Graphics LCD
• Power Source: Built in Lithium Rechargeable battery
• Accuracy: /2%
• Data Storage: 5000 or 10000
• Computer Interface: RS 232, USB
• Sensor Life: 4-5Years
• Operating Time: 6 – 8 hours
• Temperature:-15degree Celsius
• Humidity :< 85%RH Atmosphere
• Sample Inlet Pressure: 12kg/cm2
• Housing: High Impact Plastic
• Dimension in mm: 130 (W) X 250 (H) X 90(D)
• Weight: 0.5 KG
• Warranty: One Year







Product Details:

Application:

• Compressed Air
• Industrial Process Control
• Drying system
• Protection systems
• Glove box
• Turbines
• HVAC
• Breathing air

Specification:

• Probe: Capacitive Thin film water vapor sensor
• Parameters (selectable) :Dew point, Moisture , Humidity,Vapor Pressure, Temperature
• Range: Dew Point : -60 to + 30 deg C( other Ranges are Optional)
• Moisture : 0- 23000 PPM
• Humidity : 0-100%
• Vapor pressure : 0-17.5mm Hg
• Temperature : 0-80 deg C
• Dew Point Accuracy : +/-1 deg C from 0 deg C to 30 deg C dew point, +/-2 deg C from  -60 deg C to 0 deg C
• Analog output:  4-20 mA
• Resolution: 0.1
• Max Sample Temp: 80 deg C
• Max Pressure: 12kg/cm2
• Response Time: 10 sec  for 63% step change
• Display Type: Alphanumeric LCD / 31/2 Digit LED ( Optional)
• Housing : High Impact plastic
• Power: 220V/50Hz,110 V/50Hz optional
• Output relay: 5AMP,220 volts rating
• Dimension: 254 x180x 90 mm
• Additional Features
• Computer Interface: Rs-232
• Data Logger: 32kbyte, Non-Volatile Memory

Product Details:

Digital Online Dew Point Analyzer Ideal for precise monitoring of moisture or dew point in air or gas output from dryers system or in process. Continous monitoring of dew point results in reduced maintance costs and downtime caused by separated moisture, The main cause of corrosion in pneumatic systems. the analyzer usesa highly accurate capacitive integrated thin film water vapor sensor,and is an economic alternative to the chilled-mirror dew point type meters. It utilizes microprocessor based circuits to give a direct read out in dew point or other units and other units corresponding to sensor output based on psychometric equations. To achieve higher accuracies it uses temperature compensation over complete operational range.The insturment is contained in a high impact plastic housing.

Application:

• Compressed air
• Industrial process control
• Drying system
• Protection systems
• Glove box
• Turbines
• HVAC & Breathing air

Specification:

Product Details:

Black Colour Portable Dew Point Monitor are designed to measures dew point,Moisture and temperature faster and accurately over a wide measurments range. It is highly optimized to measure the dew point, moisture and Temperature for dryers and compressed air/gases. Periodic monitoring of industrial Air sytems results in a reduced maintenance cost & down time caused bycondensate, the leading cause of corrosion in pneumatic systems. Air or Gas samples up to 12kg /cm2 pressure and temperature up  to 75 deg C  can be directly measured. For higher temperature applications. a Heat sink tubing can be used. The meter can also be connected to a vacuum pump forsampling from systems at low or atmospheric pressure. Measures the dew point precisely by utilizing a highly reliable microprocessor based electronic circuit to convert the sensor signal by the use of psychometrics equations. Assembled in a ABS plastic housing, it sensor mainfold with an orifice that means line pressure for true pressure dew point readings.

Application:

• Dryer & Compressed Air
• Process drying & Laboratory Analysis
• Light bulb manufacturing
• Industrial gas manufacturing
• Heat treatment
• Petrochemical / Petroleum industry

Specification:

• Principle : Capacitive Thin Film Polymer
• Dew Point range: -60 deg c to + 30 deg c (Standered), -80 deg c to +30 deg c (Optional)
• Accuracy: 0 deg c to  + 30 deg c = +/-1 deg c
• Response time: 10 seconds for 63% step change
• Display: 128x64  Graphics LCD
• weight : 450 gm
• Additional features (Optional)
• Computer interface : RS-232 link for Data in ASCII Delimited Format, 9600 Baud, 8 Bits , 1 stop,1 start, No Parity.
• Data Logger: 32 Kbyte , Non-Volatile Memory.

Product Details:

Handheld Dew Point Meter model ATS 301D with range of -60 to +30 deg C for the application of compressed air/Nitrogen application all 4 parameter RH, TEMP, dew point and moisture on single display.

Features:

• USB/RS232 computer interface
• High back up lithium battery
• High reolution graphics display 128 x 64

Product Details:

ATS-303D Online Dew Point  Analyzer Process Dew Point Analyzer Designed to Handle Rigorous Demands of Moisture and Dew Point Measurement in Compressed air & Natural Gas Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution forDemanding and Critical Moisture Monitoring Applications.

Specification:

• Range -60 +30 Deg C / -80 + 30 Deg C
• ReResolution 0.1 Deg C
• Sensor Thin Flim Capacitive Sensor
• Accuracy +/-2%
• Output - 4-20mA

Application:

• Natural Gas
• Hydrocarbon Processing
• Catalyst Protection
• Heat Treating
• Industrial Gases
• Dryer & Compressed Air

Product Details:

Online Dew Point Meter Manufacturers In Mumbai Model ATS-303D Process Dew Point Meter Designed to Handle Rigorous Demands of Moisture and Dew Point Measurement in Compressed air & Natural Gas Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution forDemanding and Critical Moisture Monitoring Applications.

Specification:

• Range -60 +30 Deg C / -80 + 30 Deg C
• Resolution 0.1 Deg C
• Sensor Thin Flim Capacitive Sensor
• Accuracy +/-2%
• Output - 4-20mA

Application:

• Natural Gas
• Hydrocarbon Processing
• Catalyst Protection
• Heat Treating
• Industrial Gases
• Dryer & Compressed Air
• Breathing Air
• HVAC

Product Details:

We are engaged in offering our clients a high quality range of Handheld Digital Portable Dew Point Meter. The offered meter is manufactured as per the set industry standards using quality approved raw-material and latest technology. Offered meter is designed to measures dew point, Moisture and temperature faster and accurately over a wide measurements range .Keeping in mind the diverse necessities of our clients, we provide thus meter in various specifications. In order to ensure the quality of the offered meter products, our skilled professionals perform a series of test against various parameters. Relative humidity and dew point both give us an idea of the amount of moisture in the atmosphere; however only dew point is a true measurement of the atmospheric moisture. Relative humidity is defined by the National Weather Service as the amount of atmospheric moisture present, relative to the amount that would be present if the air were saturated. But what does that really mean In short, the relative humidity is a function of both the moisture content in the atmosphere and the actual air temperature. By itself, it does not directly indicate the amount of moisture present in the atmosphere.

Features:

• Smooth functioning
• Low maintenance
• Sturdiness

Application:

• Dryer & Compressed Air
• Laboratory Analysis
• Light bulb manufacturing
• Industrial gas manufacturing
• Heat treatment/Food Packaging
• Petrochemical / Petroleum industry

Specifications:

• Principle Thin Film Capacitive
• Range Degree C, PPM & % RH
• Resolution 0.1 Unit or 1 Unit (Application based)
• Sampling Method Direct Plug In
• Display 128 X 64 Graphics LCD
• Power Source Built in Lithium Rechargeable battery
• Accuracy +/2%
• Response Time <5 Second
• Data Storage 5000 or 10000
• Computer Interface RS 232, USB
• Sensor Life 2-3 Years
• Operating Time 6 - 8 hours



Environmental:

• Temperature-15degree Celsius Humidity < 85%RH Atmosphere Pressure 86- 106Kpa
• Housing High Impact Plastic
• Dimension in mm 130 (W) X 250 (H) X 90(D)
• Weight 0.5 KG
• Warranty One Year

Product Details:

Application:

• Dryer & Compressed Air
• Process drying & Laboratory Analysis
• Light bulb Manufacturing
• Industrial gas Manufactring
• Heat Treatment
• Petrochemical / Petroleum Industry

Specification:

• Range: -60 to +30 deg c / -80 to +30 deg c (Optional)

Product Details:

Portable Dew Point Moisture Meter are designed to measures dew point, Moisture and temperature faster and accurately over a wide measurements range.Model ATS 301D is highly optimized to measure the dew point , moisture and Temperature for dryers and compressed air/gases. Air or Gas samples up to 12kg/cm2 pressure and temperature up to 75 deg C can be directly measured . For higher temperature applications , a Heat sink tubing cab be used. The meter can also be connected to a vacuum pump forsampling from systems at low or atmospheric pressure. ATS 301D Measures the dew point precisely by utilizing a highly reliable microprocessor based electronic circuit to convert the sensor signal by the use of psychometrics equations, Assembled.

Product Details:

Model ATS-303D Process Moisture Analyzer Designed to Handle Rigorous Demands of Moisture Measurement in Natural Gas Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution for Demanding and Critical Moisture Monitoring Applications. The advantages of a linear high capacitance response are: better sensitivity, better repeatability and faster response times. Also, the measurement system is less prone to noise and drift, and signal conditioning is kept to a minimum. The dew point meter is operated through a menu driven user interface consisting of a custom LCD display with backlight, and four push buttons.This dew point system has proven to produce consistently accurate monitoring results for dew point in natural gas and other difficult hydrocarbon processing applications, where conventional analyzers have failed.

Features:

• High Confidence in Measurement
• Automatic Field-Calibration/Validation
• Long Sensor Life
• Low Maintenance and Low Installation Cost
• Inbuilt thin film capacitive sensor
• 128 X 64 Graphics LCD Display embedded software for moisture calculation
• Optional Sampling systems
• Data Logger with RS 232- USB Computer Interface.



Specification:



Product Details:

Dew Point Moisture Analyzer Designed to Handle Rigorous Demands of Moisture Measurement in Natural Gas Applications, Provides Fully Automatic Self-Calibration Dew Point System, Provides Cost Effective Solution for Demanding and Critical Moisture Monitoring Applications.The advantages of a linear high capacitance response are: better sensitivity, better repeatability and faster response times. Also, the measurement system is less prone to noise and drift, and signal conditioning is kept to a minimum.The dew point meter is operated through a menu driven user interface consisting of a custom LCD display with backlight, and four push buttons.This dew point system has proven to produce consistently accurate monitoring results for dew point in natural gas and other difficult hydrocarbon processing applications, where conventional analyzers have failed.

Specification :

• Principle Thin Film Capacitive
• Range Degree C, PPM % RH
• Resolution0.1 Unit or 1 Unit (Application based)
• Sampling Method Direct Plug In
• Display128 X 64 Graphics LCD
• Power Source Built in Lithium Rechargeable battery
• Accuracy/2%
• Response Time
• Data Storage5000 or 10000
• Computer Interface RS 232, USB Sensor
• Operating Time 6 – 8 hours
• Dimension in mm130 (W) X 250 (H) X 90(D)
• Weight0.5 KG
• Warranty One Year







Product Details:

Application:

• Compressed Air
• Industrial Process Control
• Drying system
• Protection systems
• Glove box
• Turbines
• HVAC
• Breathing air

Specification:

• Probe: Capacitive Thin film water vapor sensor
• Parameters (selectable) :Dew point, Moisture , Humidity,Vapor Pressure, Temperature
• Range: Dew Point : -60 to + 30 deg C( other Ranges are Optional)
• Moisture : 0- 23000 PPM
• Humidity : 0-100%
• Vapor pressure : 0-17.5mm Hg
• Temperature : 0-80 deg C
• Dew Point Accuracy : +/-1 deg C from 0 deg C to 30 deg C dew point, +/-2 deg C from  -60 deg C to 0 deg C
• Analog output:  4-20 mA
• Resolution: 0.1
• Max Sample Temp: 80 deg C
• Max Pressure: 12kg/cm2
• Response Time: 10 sec  for 63% step change
• Display Type: Alphanumeric LCD / 31/2 Digit LED ( Optional)
• Housing : High Impact plastic
• Power: 220V/50Hz,110 V/50Hz optional
• Output relay: 5AMP,220 volts rating
• Dimension: 254 x180x 90 mm
• Additional Features
• Computer Interface: Rs-232
• Data Logger: 32kbyte, Non-Volatile Memory
