The ATS Make Dew point Transmitter makes monitoring dew points as easy as measuring temperature or pressure, and can be instantly incorporated into air or gas measurement and control systems. Applied highly automated manufacturing, calibration and test processes make the transmitter not only a very rugged and reliable instrument but also very competitive in price. By taking advantage of Applied exchange sensor program, users can be assured that their process moisture measurement facility is never interrupted. It is very easy to install and maintain and comes with wide backup and service program.

TECHNICAL SPECIFICATION -:
-: Measurement Range (dewpoint) -60 to +30°C dew point,-80 to +30°C dew point & -100 to +30°C dew point (Optional)
-: Accuracy (dewpoint) ±2°C dew point
-:Response Time 1 min to T95 (dry to wet)
-: Repeatability 0.5°C dew point
-: Calibration Traceable 7 point calibration certificate

ELECTRICAL INPUT/OUTPUT-:

-: 4-20 mA current source, configurable over the end re range
-: Supply voltage 8 - 36 VDC from Control Unit
-: Load Resistance Max 660 Ω @ 24 V 160 Ω @ 12 V
-: Current Consume on 23mA max

OPERATING CONDITIONS-:
-: Operating Temperature -40 to +60°C
-: Operating Humidity 0–100% RH
-: Operating Pressure 40 MPa (450 Bar g)
-: Max Flow Rate 0.2 to 5 l/min mounted in standard sampling block; 0 to 10 ms-1
